    10-4000m3/h Submersible Chemical Pump 50Hz 60Hz Submersible Propeller Pump

    Submersiblel Pump QW Series for Raw Water Supply and Drainage
    QW/WQ series submersible pump, it is widely used in the raw water in-taking, irrigation, drainage applications, and also widely used in the civil water supply, industrial water delivery, sewage discharge, construction site, mining, etc. It is easy using, simple installation and easy movable.
    Main Performance Data
    Flow: 10 - 4,000 m3/h
    Delivery Head: 5-40m
    Outlet Dia.: 25-500mm
    Working Pressure: ≤ 1.5Mpa
    Solid Particle: ≤ 80mg/L
    Liquid Temp.: 0℃-80℃
    Model Instruction
    E.G:100QW100-15-7.5
    100: Outlet diameter
    QW: Submersible pump
    100: Flow capacity
    15: Delivery head
    7.5: Motor power

    Applications
    Industrial water supply and drainage,
    Civil water supply & treatment
    Irrigation & Drainage,flood water disposal,
    Oil, gas & petrol liquid processing,
    Hot water & raw water transferring,
    Chemical & Sea water transferring,
    Power station water circulation,
    Factory & residential fire fighting,
    Mining water supply & drainage,
    Main Parts Configuration
    The pump could be applied to transfer different kinds of liquid by customized wet parts, here followed our recommendation of main configuration:
    Parts NameFor Clean WaterFor SewageFor Corrosive Liquid
    Pump CaseCast Iron HT250Ductile Iron/Cast SteelS.S304
    ImpellerCast Iron HT250Ductile Iron/Cast SteelS.S304
    ShaftCarbon Steel 45#S.S420(2Cr13)S.S304
    Shaft SleeveCarbon Steel 45#S.S304S.S304
    BearingChina Make/NSK/SKFChina Make/NSK/SKFChina Make/NSK/SKF
    SealsMechanical SealsMechanical SealsMechanical Seals
